    Load Cell | Through Hole Donut



    The Thru Hole Donut Load Cell Series offers 4 models built for Off-Center Loading, Press, or Inline compression applications. These models have a very robust construction available in 17-4 Stainless Steel, with an I.D. range of 1/8" to 1 1/4" with capacity available up to 22 Ton or 50,000 Ibs

    Thru Hole Donut Load Cell
    Low Profile Thru Hole Donut Load Cell (High Capacity)
    The Donut/Thru Hole Load Cell also offer high accuracy and high stiffness. The standard models can be modified or customized to meet your requirements and most models are available in our inventory making it available for 24 hour shipping. Similar to our entire Load Cell product line this model is manufactured in USA and uses metal foil strain gauge technology.

    Weight: 2 oz to 85 lbs
    Resistance to High Extraneous Loads
    Low Deflection
    17-4 Steel Construction
    Compression
    Utilizes Metal Foil Strain Gauge Technology
    High Accuracy




    Load Cells - LTH300 - Donut Load Cell

    Donut Load Cell
    50~1,000 Ib

    Load Cells - LTH300 - Donut Load Cell

    Donut Load Cell
    100~5,000 Ib

    Load Cells - LTH400 - Donut Load Cell

    Donut Load Cell
    250~10,000 Ib

    Load Cells - LTH500 - Donut Load Cell

    Donut Load Cell
    2,000~50,000 Ib
